Product Details:
Payment & Shipping Terms:
|
High Light: | photo laminator machine,heavy duty laminator |
---|
Adjustable Heat Lamination Machine 2000 Watt With Electromotive Driven
Product Description and Advantage:
1) Control panel is by Micro-Processor controller, which light touching the key operate, this feature is peculiar to our company. With advanced design, better appearance and practical.
2) Reversible working platform, for convenient maintenance and space saving.
3) Adjustable rotating roller, ensure a fine smooth surface without fold, without bubble.
4) Adjustable automatic rolling system of swelling mechanism, ensures a fine rollup materials without distortion, labour saving and space saving.
5) Leaning preventing T-square, a feature of great originality in the industry which is designed to prevent the deviation. convenient in use.
6) The passive membrane feeding system of swelling mechanism, increases the Ductility of membrane and makes the surface more smooth.
7) With backup bracket, easy to take, help saving your minimal resources available.
8) One machine with two functions, the membrane's base can be collected by the swelling roller automaticly during cold laminating mode. easy and fast to operate, help to save time and manpower.
Feature:
1) Low down the cost (even to USD0.4/sqm in Canton, China). Bright in color, and in good reproduction.
2) Fine in surface flatness, no fold, no bubble, no dustiness, no discolorment. independent of environmental temperature, unaffected by climate, good color rendition and diaphaneity.
3) With the laminating speed up to 200sqm/hr. time saving, space saving, labor saving.
4) Reduce probllems of waste Disposal after use.
5) With two laminating options of operating mode, thermal laminating mode also another cold mode.
6) Wide applacition in use, much suitable for indoor printing work.
7) Laminate membrane on variety of materials such as printing paper, photographic paper, reflective flex, glass plate, wood board, etc.
8) Our company offer the service of making working table for supporting unflexable materials with the machine, according to the customer's requirement.
OEM welcomed: Our company offer the service of OEM to the customers. Such as OEM Model 1300/1950, 1300/1600/1900.
1.6m photo laminating machine/ 1600mm photo lamination machine
Specificaton Parameters: | |||
Model | ZS-FY1300 | ZS-FY1600 | ZS-FY1900 |
Diameter of Laminating Roll: | 130mm | ||
Max. filming width: | 1300mm | 1600mm | 1900mm |
Max. filming thickness: | 30mm | ||
Speed range: | Adjustable, 0-4m/min | ||
Temperature range: | Adjustable, environmental - 125C | ||
Warm up Time | 10-20 min | ||
Laminating mode: | electromotive driven | ||
Pressure adjusting mode: | Linkage Regulation of coordinated control | ||
Max. Power Consumption: | 0.9kwh | 1.0kwh | 1.2kwh |
Input Frequency: | 50-60HZ | ||
Rated input Voltage: | 110/220(optional) | ||
Rated Input Power: | 2000watt | 2500watt | 3000watt |
Net Weight Of the Machine: | 185kg | 204kg | 235kg |
Dimension(L*W*H): | 1770mm*700mm*1200mm | 2070mm*700mm*1200mm | 2370mm*700mm*1200mm |
Net Weight Of Extra Platform: | 100kg | 120kg | 150kg |
Extra Platform unit Size/Unit,L*W*H(mm): |
1200*1350*850*4units | 1200*1650*850*4units | 1200*1950*850*4units |
With 4 units as default. Can be a combination of one or more units in case of need. |
1.6m photo laminating machine/ 1600mm photo lamination machine
Packing Description: | |||
Gross Weight Of The Laminator: | 240kg | 258kg | 290kg |
Packing Dimension Of The Laminator: | 182cmx70cmx72cm | 212cmx70cmx72cm | 242cmx70cmx72cm |
Packing Volume Of The Laminator: | 0.92CBM | 1.10CBM | 1.22CBM |
Gross Weight Of Extra Frame: | 130kg | 160kg | 190kg |
Packing Dimension Of Extra Frame: | 127cmx138cmx54cm | 127cmx168cmx54cm | 127cmx198cmx54cm |
Packing Volume Of Extra Frame: | 0.95CBM | 1.16CBM | 1.36CBM |
Manner Of Packing: | Shake-Proof Wooden Case with foam packaging inside |
We also offer OEM service for our customers!Range(color,hight,trademark,etc.)
Minimal Quantity Order: 1pc;
Factory Price:Negotiable;
all machines will be packed in strong wood box to ensure safty shipping.
After-sale-service:
1.6m hot / cold laminator machine/ 1600mm photo lamimation machine
1. We provide 24 months warranty for boards and motors for our equipment
2. When you have some technical problems,please send detail description,photos or video,then our technician will give the resolution accordingly during 24 hours.
3. There are completed English user manuals to guide you easily install ,operate and maintain the printer. It’s clear and easy to understand.
4. Free training is availabe when you need it, you are welcome to our factory to obtain the skills. or we also send engineer to your company to make a training for your people ( you charge of the tickets)
with 15 years export experience in the large format printers industry, High quality, safe packing, on-time delivery and good after service are OUR KEY.
